The AT24C16C-SSHM-B is a 16K, 2-wire Serial EEPROM IC (electrically erasable and programmable read-only memory) designed for use in various digital and analog applications, providing non-volatile memory storage and retrieval capabilities.
AT24C16C-SSHM-B Key Features
- 16K-Bit Serial EEPROM: The AT24C16C-SSHM-B offers 16,384 bits of electrically erasable programmable read-only memory, providing ample storage capacity.
- 2-Wire Serial Interface: This IC features a 2-wire serial interface (I2C) for easy integration with microcontrollers and digital systems.
- Low Power Consumption: With low standby and active currents, the AT24C16C-SSHM-B is suitable for battery-powered applications.
- Write Protect Pin: The WP pin allows the device to be write-protected, safeguarding stored data from accidental writes.
- Wide Voltage Range: The IC can operate within a wide voltage range, making it suitable for various applications.
AT24C16C-SSHM-B Applications
- Data Storage: The AT24C16C-SSHM-B is commonly used for storing configuration data, calibration parameters, and other non-volatile information in digital systems.
- Embedded Systems: This IC is suitable for use in embedded systems, providing non-volatile memory for program and data storage.
- Sensor Calibration: It can be utilized for storing calibration values and sensor data in various sensor-based applications.
Functionality
The AT24C16C-SSHM-B provides non-volatile memory storage and retrieval, enabling the retention of critical data even when power is removed from the system.
Usage Guide
- Power Supply: Connect VCC (Pin 8) to the power supply voltage and GND (Pin 4) to ground.
- Serial Interface: Utilize the SDA (Pin 5) and SCL (Pin 6) pins for 2-wire serial communication with a microcontroller or other digital device.
- Write Protection: The WP pin (Pin 7) can be used to protect the memory from inadvertent writes by connecting it to VCC or GND as per the application requirements.
AT24C16C-SSHM-B Equivalents
For similar functionalities, consider these alternatives to the AT24C16C-SSHM-B:
- AT24C32C-SSHM-B: A 32K, 2-wire Serial EEPROM IC offering higher storage capacity than the AT24C16C-SSHM-B.
- AT24C08C-SSHM-B: An 8K, 2-wire Serial EEPROM IC for applications requiring lower storage capacity.
- AT24C256C-SSHM-B: A 256K, 2-wire Serial EEPROM IC suitable for applications demanding higher memory storage.
AT24C16C-SSHM-B Specifications
| Density (Organization) |
16K bits |
Operating Voltage Min. (V) |
1.7 |
| Oper Voltage Max (V) |
5.5 |
Max. Clock Freq |
1 MHz |
| Page Size (bytes) |
16 |
Write Protected |
False |
| Write Protect Scheme |
Whole Array |
Endurance |
1,000,000 |
| Data Retention (Years) |
0 |
Battery Backup |
False |
AT24C16C-SSHM-B Frequently Asked Questions
Q: What is the maximum clock frequency supported by the AT24C16C-SSHM-B?
A: The AT24C16C-SSHM-B can support clock frequencies of up to 1MHz.
Q: Can this IC be used in automotive applications?
A: Yes, the AT24C16C-SSHM-B is suitable for automotive applications, providing non-volatile memory storage for various systems within a vehicle.
***************************************************************
