When it comes to safeguarding your electronic devices from ESD damage, the TPD3E001DRYR stands out as a reliable choice with its cutting-edge technology. Its three-channel configuration ensures comprehensive protection, while the low IO capacitance per channel maintains signal integrity in high-speed data transmission scenarios. With a maximum ESD protection level compliant with international standards and an ultra low leakage current, this diode array is a dependable solution for critical applications like precision measurements.
Key Features
- IEC61000-4-2 Level-4 ESD Protection
- ±8-kV IEC 61000-4-2 Contact Discharge
- ±15-kV IEC 61000-4-2 Air-Gap Discharge
- 5.5-A Peak Pulse Current (8/20-µs Pulse)
- I/O Capacitance: 1.5 pF (Typical)
- Low Leakage Current: 1-nA (Maximum)
- Low Supply Current: 1-nA (Typical)
- 0.9-V to 5.5-V Supply-Voltage Range
- Space-Saving DRY, DRL, and DRS Package
Options
- Alternate 2-, 4-, and 6-Channel Options Available:
TPD2E2U06, TPD4E1U06, and TPD6E001
Specifications
| Vrwm (V) |
5.5 |
Bi-/uni-directional |
Uni-Directional |
| Number of channels |
3 |
Clamping voltage (V) |
25 |
| IO capacitance (typ) (pF) |
1.5 |
IEC 61000-4-5 (A) |
5.5 |
| IEC 61000-4-2 contact (±V) |
8000 |
Dynamic resistance (typ) |
1.2 |
| Interface type |
USB 2.0 |
Breakdown voltage (min) (V) |
11 |
| IO leakage current (max) (nA) |
1 |
Rating |
Catalog |
| Operating temperature range (°C) |
-40 to 85 |
|
|
***************************************************************
