The XC2C256-7VQG100C is a CoolRunner-II CPLD (Complex Programmable Logic Device) featuring 256 macrocells and a 7ns propogation delay. This device offers reconfigurable logic for various digital applications and is built on second-generation antifuse technology.
XC2C256-7VQG100C Key Features
- 256 Macrocells: Provides ample logic elements for digital design implementations.
- 7ns Propagation Delay: Offers fast signal processing for time-critical applications.
- Reconfigurable Logic: Enables dynamic reprogramming of the device for flexibility in functionality.
- Second-Generation Antifuse Technology: Utilizes advanced technology for improved reliability and performance.
- Low Power Consumption: Operates efficiently with low power requirements.
XC2C256-7VQG100C Applications
- Digital Design: Ideal for FPGA prototyping, digital signal processing, and control applications.
- Embedded Systems: Suitable for building custom logic in embedded system designs.
- Communication Systems: Used in networking equipment and communication devices for logic processing.
Functionality
The XC2C256-7VQG100C CPLD offers reconfigurable logic with 256 macrocells, enabling efficient and customizable digital logic implementations for various applications.
Usage Guide
- Power Supply: Connect VCCINT and VCCIO to respective power supplies for internal and I/O operations.
- Configuration: Apply configuration signals SDI, CK, and CS for device programming.
- Boundary Scan Testing: Use TDI, TMS, TCK, and TDO pins for boundary scan testing of the device.
XC2C256-7VQG100C Alternative Parts
- XC2C256: The base part number for this device, which can be used as an alternative.
- XC2C256-7VQG100C: This part number is a specific variant of the XC2C256, with additional features such as in-system programmability.
Embedded Modules:
- CoolRunner II: This device is part of the CoolRunner II family of CPLDs, which are designed for high-performance and low-power consumption.
XC2C256-7VQG100C Attributes
| Product Category |
CPLD - Complex Programmable Logic Devices |
RoHS |
Details |
| Series |
XC2C256 |
Mounting Style |
SMD/SMT |
| Package / Case |
VQFP-100 |
Operating Supply Voltage |
1.8 V |
| Number of Macrocells |
256 Macrocell |
Number of I/Os |
80 I/O |
| Supply Voltage - Max |
1.9 V |
Supply Voltage - Min |
1.7 V |
| Minimum Operating Temperature |
0 C |
Maximum Operating Temperature |
+ 70 C |
| Maximum Operating Frequency |
256 MHz |
Propagation Delay - Max |
5.7 ns |
| Brand |
AMD / Xilinx |
Moisture Sensitive |
Yes |
| Number of Logic Array Blocks - LABs |
16 |
Operating Supply Current |
21 uA |
| Product Type |
CPLD - Complex Programmable Logic Devices |
Factory Pack Quantity |
1 |
| Subcategory |
Programmable Logic ICs |
Tradename |
CoolRunner-II |
| Unit Weight |
0.697093 oz |
|
|
XC2C256-7VQG100C FAQs
Q: What is the maximum delay time of this device? A: The maximum delay time is 6.7ns.
Q: Is this device lead-free? A: Yes, this device is lead-free.
Q: What is the operating temperature range of this device? A: The operating temperature range is 0°C to 70°C.
Q: Can this device be programmed in-system? A: Yes, this device is in-system programmable.
Q: What is the supply voltage range of this device? A: The supply voltage range is 1.7V to 1.9V.
Q: What is the packaging type of this device? A: The packaging type is a tray.
Q: What is the qualification status of this device? A: The qualification status is Not Qualified.
Q: Is this device ROHS compliant? A: Yes, this device is ROHS3 compliant.
***************************************************************
